・World's Lightest Weight (including battery) 14"x17": 2.9kg / 17"x17": 3.6kg
・Energy Conservation Design:16hr Stand-by time
WIRELESS DIGITAL RADIOGRAPHY SYSTEM AeroDR
| Type | Portable flat panel detector based on amorphous silicon (a-Si) |
|---|---|
| Scintillator | CsI (Cesium Iodide) |
| Weight | 2.9 kg |
| Pixel Size | 175 μm |
| Image Field | 1,996 x 2,434 pixels (4.8 million pixels) |
| Power/Communications Tether | Possible |
| WLAN Standard | WLAN standard IEEE 802.11a |
| Dynamic Range | 4 digits |
| Dimensions (WxLxT) | 383.7 x 460.2 x 15.9 mm ※Equivalent to standard 14 x17" cassette |
| Charging Time Empty to Full | 30 minuties with battery charger |
| Operating Time | 5.5 hours / 200 images *Under conditions that the interval between studies is five minutes and three images are captured in each study. |
| Battery Life Cycle | Same as the product life cycle |
AeroDR Battery Charger
| Power | 100/110/115/120/200/230/240 VAC |
|---|---|
| Weight | 7.2 kg |
| Dimensions ( W x D x H) | 560 x 250 x 153mm |
Control Station CS-7
| Image Processing | Automatic Gradation Processing (G Processing) Frequency Processing (F Processing) Equalization Processing (E Processing) Hybrid Processing (H Processing) Hybrid Smoth Processing (HS Processing) |
|---|---|
| Image Output | Host : Up to 4 channels Printer : Up to 2 channels |
| DICOM Support | Basic Greyscale Print Management (SCU) Storage (SCU) Modality Worklist Management Modality Performed Procedure Step Greyscale Standard Display Function (print output) |
| CR / DR Connections | AeroDR : Up to 4 simultaneous active detectors REGIUS Cassette Reader : Up to 15 units |
| Main Options | ●Hardware options Bar-code Reader for REGIUS Cassette Registration In-room Sub Monitor ●Software options DICOM MWM/ MPPS/ DETACHED, FTP DICOM Storage Output DICOM Print X-ray Generator Connection Media Storage Text Annotation Automatic Body Part Recognition Automatic Processing Parameter Study |
