Spectrophotometers / Bench Top

Product Overview

Reflective Color Measurement

• SCI/SCE switchingWhen SCI is selected, measurements will be unaffected by the specimen surface condition, and this is ideal for the control of color compounding ratios and CCM. Alternatively, SCE can be selected to obtain test measurements for a condition approximating visual examination by eliminating specularly reflected light.

• Measurement area switchingMeasurement area of Φ25.4mm, Φ8mm, and 3 x 5mm can be selected according to the specimen being measured.

• Fluorescent color measurement
  UV cut filters allow 1,000-step adjustment of UV light. The approximation of a D65-equivalent light source in this way provides an ideal measurement solution for paper, pulp, and other materials containing fluorescent materials.

Transparent Color Measurement

• Measurement of transparent colors by diffused lighting, 0º reception (d/0)
  Wide-ranging support is provided for the measurement of glass filters and other sheet or plate specimens, in addition to liquid items for food products, cosmetics, etc.

Principal Applications

Plastics, textiles, dyed items, kiln-fired materials, etc.

Main Features

• Highly accurate and reliable benchtop instrument which can be controlled from a computer using Windows software.
• Features a d/8 optical system (diffused lighting; 8° reception).
• Measurement areas of Φ25.4mm, Φ8mm, and 3 × 5mm supported.
• Capable of transparent color measurement using a d/0 optical system.
• Supports the adjustment of UV light intensity for fluorescent color measurement.
